State of GeoServer Cloud

%%{ init: { "theme": "default" } }%%
flowchart TD
    Clients(["🌐 HTTP Requests"])
    Clients-. "https://.../geoserver" .-> Gateway

    subgraph Cloud [" "]
        Gateway[/"⚖️ LoadBalancer / Gateway"/]
        style Gateway fill:#cc99ff
        %% Pods Layer
        subgraph Pods [" "]
            GeoServer1["🌍 GeoServer n"]
            GeoServer2["🌎 GeoServer 2"]
            GeoServer3["🌏 GeoServer 1"]
        end
        %% Storage Layer
        subgraph Data storage [" "]
            GSDataDir[("📁 (Shared) GS Catalog/Datadir (XML)")]
            PostGIS[(🗄️ PostGIS Geodata)]
            style GSDataDir fill:#ffcc99
            style PostGIS fill:#c2d6d6
        end
    end


    Gateway --> GeoServer1
    Gateway --> GeoServer2
    Gateway --> GeoServer3

    GeoServer1 -->|read/write| GSDataDir
    GeoServer2 -->|read/write| GSDataDir
    GeoServer3 -->|read/write| GSDataDir

    Pods --> PostGIS
